• 46 •
Jar statistics
The JAR STATISTICS report shows the volt and mhos/siemens results for jars with their measured
percentages of the reference value (%REF) you selected in BATTERY SETUP. (If you tested with-
out a reference value, dashes appear in reference fi elds.) If you tested both the jars and straps in
a string, the report shows resistance measurements (μOhm) for the strap in place of the percent-
age of the reference value. JAR STATISTICS appears only in the printout and prints after STRING
STATISTICS.
Low volts
warning (!)
In MHOS column:
4 with a ? to indicate that it is
below the WARN threshold
percentage of the reference
value (FAIL= !, WARN = ?)
The analyzer uses letter
designations if the jar has
more than one set of posts
A = fi rst set of +/–
posts tested on the jar
B = second set of +/–
posts tested on the jar
Results for
JARS AND STRAPS with 4 posts
In μOhm column:
Resistance
measurements in
microhms of strap
connections
JAR STATISTICS
JAR VOLTS MHOS %REF
1 2.263 900 90%
2 2.262 890 89%
3 2.265 720 72%
4 !2.051 690? 69%
JAR STATISTICS
JAR VOLTS MHOS μOhm
J1A 2.011 224! 6
J1 B 2.263 900 9
J2A 2.262 890 7
J2B 2.262 890 6
Results for JARS
(if AC voltage/current ripple present)
JAR STATISTICS
JAR VOLTS MHOS %REF
J1 2. 263 900 90%
AC mV : 132 AC A : 2.2
J2 2. 262 890 89%
AC mV : 40 AC A : 0.6
Results for JARS ONLY (for a string of 12 V jars)
Chapter 7: Test results and reports Celltron ULTRA
