Midtronics GR1 240 User Manual

18
HANDLE INSTALLATION
CAUTION: THE GR-1 MUST BE FULLY
ASSEMBLED BEFORE OPERATING.
1. Locate the handle and hardware provided.
2. Position the handle, so that the angle faces
away from the back of the GR-1 and so that all
mounting holes line up. Refer to the drawing.
3. Use all 4 screws to attach the handle to the
back of the GR-1.
GR
-
1 ASSEMBLY
NOTES

Midtronics GR1 240 Specifications

General

Brand	Midtronics
Model	GR1 240
Category	Battery Charger
Language	English
