Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com
9
2: In Vehicle TestJDT-1
Battery Test Results
Send test results via
email.
Continue to System
Test
6
Print test results Return to Main Menu
Icons are color-coded to indicate status.
Battery Test
Starter Test
Alternator Test
Green:
All test parameters were completed and have passed.
Yellow:
Some test parameters may require further testing.
Red:
The battery has failed the test.
Gray:
Insufcent data to perform the test.
Refer to Appendix B: Decision Tables for a complete explaination
of the possible test results.
System Test
1. Tap to proceed with the System Test.
2. Start the engine and let it idle.
3. Tap Next. The analyzer tests the alternator output.
4. When prompted, rev the engine to between 2000 to 3000
rpm and hold it there while
the analyzer tests the alterna-
tor output again.
5. When prompted Idle the engine and then turn it o.
6. Tap Next to display the test results.
Refer to Appendix B: Decision Tables for a complete explaination
of the possible test results.
System Test Results
Tap the icons at the top of the screen to view specic test
results.
Battery Test
Starter Test
Alternator Test
Send test results via
email.
Return to Main Menu
6
Print test results
Refer to Appendix B: Decision Tables for a complete explaination
of the possible test results.
