a
Main switch (bottom left)
b
Hot water spout
c
Controls and display
d
Cup heating
e
Water container
f
Ground coffee chute
g
Coffee bean container
h
Grinder setting
(behind the service panel)
i
Brew unit (behind the service panel)
j
Main dispenser with cappuccinatore
k
Park position for milk pipework
(behind the service panel)
l
Drip tray with lid and grounds
container
m
Milk tube opening
n
Lower panel with drip tray cover
o
Stainless steel milk flask
