Miele CS 1013-1

Building-in several CombiSets
38
Calculating the worktop cut-out
The frames of the CombiSets overlap the worktop at the outside right and left by
8mm on each side.
 Add up the widths of the CombiSets and subtract 16mm from this figure.
Example:
288 mm + 288 mm + 380 mm = 956 mm - 16 mm = 940 mm
The CombiSets are 288mm, 380mm or 576mm wide depending on model (see
"Building-in dimensions").
Spacer bars
When building-in several CombiSets a spacer bar must be fitted between each
CombiSet. The position for securing the spacer bar will depend on the width of the
CombiSet.
