Installation
39
Preparing the worktop
Make the worktop cut-out as shown
in "Building-in dimensions" or as
calculated (see Building-in several
CombiSets). Observe the safety
distances (see "Safety distances").
Wooden worktops
Seal the cut surfaces with a suitable
sealant to avoid swelling caused by
moisture. The sealant must be heat-
resistant.
Make sure that the sealant does not
come into contact with the top of the
worktop.
Position the spring clamps and
spacer bars on or at the top edge
of the cut-out in the positions shown.
Secure the spring clamps and
spacer bars with the 3.5x25 mm
wood screws supplied.
