Installation
46
Installing the CombiSet
Feed the mains connection cable
down through the cut-out.
Starting at the front, position the
CombiSet in the worktop cut-out.
Using both hands, press down evenly
on the edges of the CombiSet until it
clicks into position. When doing this,
make sure that the seal underneath
the appliance sits flush with the
worktop. This is important to ensure
an effective seal with the worktop.
Do not use sealant (e.g. silicone).
If the seal does not meet the worktop
correctly on the corners, the corner
radii (≤R4) can be carefully scribed to
suit.
Installing several CombiSets
Push the built-in CombiSet to the
side until the holes in the spacer bar
can be seen.
Fit the cover strip in the holes in
the spacer bar .
Starting at the front, position the next
CombiSet in the worktop cut-out.
Proceed as described previously.
