Feed the connection cable down
through the cut-out.
^
Starting at the front, position the
appliance in the worktop cut-out.
^
Using both hands, press down
evenly on the sides of the appliance
until it clicks into position. When
doing this make sure that the seal
under the appliance sits flush with
the worktop on all sides. This is
important to ensure an effective seal
all round. Do not use sealant.
^
Push the appliance to the side until
the holes in the spacer bar can be
seen.
^
Fit the cover strip d into the holes in
the spacer bar b.
^
Starting at the front, position the next
appliance in the worktop cut-out.
^
Connect the appliance(s) to the
mains (see "Electrical connection").
^
Check that the appliance(s) work(s).
Once installed, the appliance can
only be removed using a special tool.
It can also be pushed up out of the
cut-out from below. It must be
pushed up from the back first.
Installing the appliance(s)
45
