Miele CS 1234-1 User Manual

Installing the appliance
^
Feed the connection cable down
through the cut-out.
^
Place the appliance into the worktop
cut-out, starting with the front of the
appliance.
^
Using both hands, press down
evenly on the sides of the appliance
until it clicks into position. When
doing this, make sure that the seal
sits flush with the worktop on all
sides. This is important to ensure an
effective seal all round. Do not use
sealant.
When installing several appliances, a
cover must be inserted into the spacer
bar.
^ Slide the installed appliance to one
side until you can see the holes of the
spacer bar.
^
Insert the cover d into the holes of
the spacer bar b.
^
Place the appliance into the worktop
cut-out, starting with the front of the
appliance.
^
Connect the appliance to the mains
electricity (see "Electrical
connection").
^
Check that the appliance works.
Removing the appliance
If the appliance is accessible from
below, push it out from underneath,
starting at the back.
In stubborn cases, or if the appliance is
not accessible from below, use a
cooktop lever (available from Miele) to
lift up the cooktop. To prevent damage
to the worktop, position a cloth or
similar under the cooktop lever.
Warning: Do not use a screwdriver to lift
up the cooktop as this will damage the
appliance.
Installing/removing the appliance(s)
43
