Installation
*INSTALLATION*
45
Installation dimensions EVS 7010
Installation in a tall or base unit
If the drawer is to be installed in a housing unit underneath a cooktop, please
also observe the installation instructions for the cooktop as well as the casing
depth required for the cooktop.
a
Countertop protrusion ≤ 11 7/16" (29mm)
