Fit the side seals for the inner pane
in the grooves provided.
Insert the inner pane with the printed
text facing downwards.
Be careful that the side seals do not
slip and that the pane is pushed in
as far as possible.
Fit the trim with the seal in front of
the glass panes.
Make sure that the seal is sitting cor-
rectly to prevent any steam penetrat-
ing inside the door.
Put the guides back in position, then
tighten the screws in the trim.
Correcting minor faults
63
