The glass cover is held in position by
two metal brackets which are secured
to the reflector.
Do not push the metal brackets to
the sides, as this would damage
both the brackets and the reflector.
It might also make it difficult to push
the glass cover back into its frame
again.
^
Pull the glass cover out of the rear
metal brackets.
^
Pull the defective halogen lamp out.
When purchasing a new lamp it is a
good idea to take the old one with
you to make sure you get the correct
replacement (12 V, 20 W, heat
resistant to 300 °C, G4 fitting,
Osram, Type 64428).
Do not touch the surface directly
when changing the lamp as grease
particles from your fingers will
adhere to the surface and damage
the lamp. Please follow the
manufacturer’s instructions.
^ Replace it with a new one, making
sure it goes into its socket
horizontally.
^
Push the glass cover back into the
metal clamps with the cut out edge
towards the rear.
Problem solving guide
72
