Notes on installation
17
1 2 3
a
Backguard
b
Rear panel backguard
c
Inside panel
 Place
the backguard  face down on
a soft surface to avoid scratching.
The lower edge should line up with
the edge of the table, so that the
backguard lies flat.
 L
oosen the screws on the back of
backguard.
 Remove the rear panel  and the
inner panel .
1
2
a
Backguard
b
Range
 Slide the backgu
ard  from above
on the air duct extenders.
