Electrical connection
79
Electrical connection
Type Connecting
line
NEMA Electrical supply
HR 1421 approx.
5' 11"
(1.80 m)
14-50 P
plug
120/208 V 50 A 60 Hz
HR 1421 approx.
5' 11"
(1.80 m)
14-50 P
plug
120/240 V 50 A 60 Hz
HR 1622
HR 195x
approx.
5' 11"
(1.80 m)
14-50 P
plug
120/208 V
or
120/240 V
50 A 60 Hz
HR 192x
HR 193x
approx.
5' 11"
(1.80 m)
14-30 P
plug
120/208 V
or
120/240 V
30 A 60 Hz
HR 112x
HR 113x
approx.
5' 11"
(1.80 m)
5-15 P plug 120 V 15 A 60 Hz
Data plate
The data plate with the connection information for the range is located in the
middle of the base fr
ont behind the removable toe kick cover (see "Guide to the
range").
SAVE THESE INSTRUCTIONS FOR THE ELECTRICAL INSPECTOR'S USE.
