Anti-tip device
76
Complete all necessary
connections
for the range. Read the
information in the "Electrical
connection", "Gas connection" and
"Plumbing" sections.
The range can be damaged if it is
lift
ed using the cover, the trim or
the door handle.
Open the oven door and hold the
applianc
e by the front of the oven
interior.
Lift the range and move it with the
help of the rear wheels.
Slide the r
ange into position, guiding
the middle of the appliance onto the
anti-tip device. Slide the appliance all
the way back to the wall.
Use a level to align the range
– Left and right rear adjustment :
Y
ou will need a 3/8" (10 mm)
open-end wrench.
– Left and right front adjustment :
Y
ou will need a 5/8" (16 mm)
open-end wrench for the locknut
and an open-end wrench (1/2" (13
mm)) for the adjustable nut.
