Slide SoftClose mechanism bracket
f as far as it will go towards the
handle side of the door, and undo
screws g on the SoftClose
mechanism.
^ Using a flat-bladed screwdriver, slide
the SoftClose mechanism towards
the handle side of the door, and lever
it out at the side.
^ Then place it to one side.
Changing over the door
Remove any food from the door
shelves.
^
Close the appliance door.
^ Remove cover a by sliding it
forwards from the back and then
lifting it off.
^ Remove cover b by pulling it
upwards.
Caution! The appliance door is not
secure once the hinge plate has
been removed.
^
Loosen screws d in upper hinge
plate c and pull it upwards and off.
^
Carefully lift the door off and place it
to one side.
^
Gently loosen cover e by carefully
inserting a flat-bladed screwdriver
into the gap.
^
Remove cover e together with
retaining plate f.
Changing the door hinging
54
