Miele K 31222 Ui Manual

10841790-04
Installing the appliance
*INSTALLATION*
With furniture with door fittings (e.g.
stubs, seals etc.) the dimension of
these must be taken into account
when making sure there is a gap all
round of 42mm.
 Pull the appliance forwards by the
appropriate dimension.
 Check again to make sure there is a
gap of 42mm to the front edges of
the door fittings.
Useful tip: If possible, remove door
fittings and push the appliance into the
niche until all fixing brackets at the top
and bottom are in line with the front
edge of the housing unit side wall.
Aligning the appliance
When securing the appliance in the
niche at the top, the appliance
should sit lightly tensioned between
the floor and the worktop.
 Adjust the front and rear feet
alternately according to the height of
the niche and make sure the
appliance is correctly aligned.
Proceed as follows:
 Adjust both rear feet with appropriate
screws at the front right and left in the
appliance plinth using a flat-tip
screwdriver.
 Use an Allen key to unscrew both
front feet.
Useful tip: As soon as the feet have
been unscrewed slightly, you can adjust
them with a screwdriver at the bottom
of the foot (see small illustration).

Miele K 31222 Ui Specifications

General

Door hinge	Right
Control type	Buttons
Product color	-
Reversible doors	Yes
Appliance placement	Built-in
Door panel included	No
Fridge door balconies	2
Number of vegetable drawers	1
Fridge number of shelves/baskets	4
Lamp type	LED
Cord length	1.9 m
Noise level	35 dB
Climate class	SN-ST
Fridge net capacity	137 L
Fridge gross capacity	- L
Current	10 A
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	115 kWh

Weight and Dimensions

Depth	552 mm
Width	597 mm
Height	818 mm
Weight	38100 g
Installation compartment depth	550 mm
Installation compartment width	600 mm
Installation compartment height	870 mm
