Cooking zone sensors and displays
l Displays:
0 = Cooking zone ready for use
1 to 9 = Power setting
# = Residual heat
F = Fault (see "Safety switch-off")
A = Auto heat-up when the power setting range has been extended
P0 etc. = Programme (see "Programming")
S0 etc. = Status (see "Programming")
m Indicator lamp for Auto heat-up or extended power setting (see "Programming"),
e.g. the front left cooking zone
n Power setting sensor switches
Timer sensors and display
o Sensor switches for setting the timer, switching between timer functions and
selecting automatic switch-off for a cooking zone.
p Sensor switches to set the timer
q Timer display
r Indicator lamp for automatic switch-off, e.g. of the rear right cooking zone
Guide to the appliance
