Solid wood, tiled and glass worktops
a Worktop
b Hob
c Gap
d Wooden frame 13 mm
(to be provided on site)
As the ceramic glass and the
worktop cut-out have a certain
dimensional tolerance, the size of
gap c can vary (min. 1 mm).
^
Make the worktop cut-out as shown
in "Building-in dimensions".
^
Fix the wooden frame d 7mm
below the top edge of the worktop
(see diagram).
^
Feed the hob connection cable down
through the cut-out.
^
Centre the hob b in the cut-out.
^
Connect the hob to the mains.
^
Check that the hob works.
^
Seal the remaining gap c with a
silicone sealant that is heat-resistant
to at least 160 °C.
Observe the silicone sealant
manufacturer’s instructions.
For granite and marble tiles, only
use silicone sealant that has been
especially formulated for granite and
marble.
Flush-fitted hobs
79
