Hob with frame or bevelled
edges
Seal between the hob and the
worktop
The sealing strip under the edge of the
top part of the appliance provides a
sufficient seal for the worktop.
The hob must not be sealed with
sealant (e.g. silicone).
This could result in damage to the
hob or the worktop if the hob ever
needs to be removed for servicing.
Tiled worktop
Grout lines a and the hatched area
underneath the hob frame must be
smooth and even. If they are not the
hob will not sit flush with the worktop
and the sealing strip underneath the
hob will not provide a good seal
between the hob and the worktop.
Safety instructions for installation
57
