Miele KM 6839 - Flush-fit Hob Installation

Flush-fitted hobs
70
Installation
Natural stone worktops
a
Worktop
b
Hob
c
Gap
As the ceramic glass and the worktop
cut-out have a certain dimensional
tolerance, the size of the gap can
vary (min. 2mm).
KM 6639 / KM 6839
d
Stepped cut-out
KM 6679 / KM 6879
d
Stepped cut-out
Solid wood, tiled and glass worktops
a
Worktop
b
Hob
c
Gap
d
Wooden frame (13mm) (to be
provided on site)
As the ceramic glass and the worktop
cut-out have a certain dimensional
tolerance, the size of the gap can
vary (min.2mm).
