Technical data
123
Height
820mm (adjustable + 60mm)
Height with lid
835mm (adjustable + 60mm)
Width
598mm
Depth
Depth with door open
600mm
1,200mm
Weight (net)
70kg
Voltage, rated load, fuse rating See data plate
Connection cable
Approx. 1.7m
Water temperature:
Cold water connection
Hot water connection
Max. 20°C
max. 60°C
Static water connection pressure
Max. 1,000kPa (10bar) overpressure
Recommended water connection pressure:
Cold and hot water connection
Water connection for steam condenser
200kPa (2bar) overpressure
100kPa (1bar) overpressure
Minimum water connection pressure:
Cold water connection
Hot water connection
100kPa (1bar) overpressure
40kPa (0.4bar) overpressure
Delivery head
Min. 0.3m, max. 1.0m
Drainage length
Max. 4.0m
Ambient temperature
5°C to 40°C
Relative humidity
Maximum
Linear decreasing to
80% for temperatures up to 31°C
50% for temperatures up to 40°C
Altitude above sea level
To 2,000m*
Inlet hoses
Approx. 1.7m
Drain hose
Approx. 1.5m
Safety class (according to DINEN60529)
IP21
Noise emission values
Sound power in LwA
Sound pressure in LpA
Built-under dishwasher with wooden beam in front of plinth on
Short programme
57dB(A)
45dB(A)
Test certification VDE, EMC radio suppressed
CE mark 2006/42/EC Machinery Directive
UKCA mark (UK only) The Supply of Machinery (Safety) Regulations 2008
Manufacturer address Miele & Cie. KG, Carl-Miele-Straße 29,
33332 Gütersloh, Germany
* If installed above 2,000m, the boiling point of the wash water will be lower. Commercial dishwashers installed above
this altitude must be modified by the Miele Customer Service Department.
