Installation
*INSTALLATION*
41
Installation
Preparing the worktop
Make the worktop cut-out as shown
in “Building-in dimensions” or as
calculated (see “Installing several
ProLine elements” in the “Installation”
chapter). Remember to maintain the
minimum safety distances (see
“Installation – Safety distances”).
Wooden worktops
Seal any cut surfaces on wooden
worktops with a special varnish,
silicone sealant or resin to prevent the
wood from swelling as a result of
moisture ingress. The sealant must
be heat-resistant.
Make sure that the sealant does not
come into contact with the top of the
worktop.
Position the spring clamps and the
spacer bars at the top edge of the
cut-out in the positions shown in the
illustrations.
Secure the spring clamps and
spacer bars with the 3.5x25mm
wood screws supplied.
