Programming
158
Run the hose of the dispenser pump that is being checked upwards
into a measuring vessel.
Irritant detergents!
Can cause skin and eye irritation.
Avoid contact with skin and eyes, wear protective clothing.
Return to the main menu by pressing "Back".
Dispenser calibration
Main menu
Dispenser pump 1
Dispenser pump 2
Select a dispenser pump.
Dispenser calibration
Dispenser pump 1
0/1
0t:
P: No
100 mlV:
s
Press multifunction button0/1.
Stop the pump by pressing button0/1, or the pump will stop
automatically after 60seconds.
Measure the required amount into the measuring vessel.
Dispenser calibration
Dispenser pump 1
0/1
30 st: P: 200 ml/minV: 100 ml
Enter the amount measured in field"V:".
The throughputP is calculated in ml/min by the controls.
Press the "Save" button.
The measured value is assigned to the pump.
Reattach the hose.
