Miele TSB 143 WP User Manual

Warnings and safety instructions
10
 This tumble dryer is supplied with a special lamp to cope with
particular conditions (e.g. temperature, moisture, chemical resist-
ance, abrasion resistance and vibration). This special lamp must only
be used for the purpose it is intended for. It is not suitable for room
lighting. Replacement lamps may only be fitted by a Miele authorised
person or the Miele Service Department.
 This tumble dryer uses a gaseous refrigerant which is condensed
by the compressor. Having been increased to a high temperature
level as as result of the condensing process, the refrigerant passes
through a closed refrigerant circuit. The heat generated is transferred
to the drying air as flows through the heat exchanger.
– The humming noises caused by the heat pump during the drying
process are normal. They do not impair the efficient functioning of
the tumble dryer.
– The refrigerant is environmentally friendly and causes no damage
to the ozone layer.
 Damage to the tumble dryer by switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer, wait for at least one hour before
starting a drying programme.

Miele TSB 143 WP Specifications

General

Drum type	Honeycomb
Door color	White
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Drum volume	120 L
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Delay start (max)	24 h
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Number of drying programs	11
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
