Miele TSB 143 WP User Manual

Fragrance flacon
37
Inserting a fragrance flacon
 Open the door of the tumble dryer.
The fragrance flacon is inserted in the
upper fluff filter in the opening on the
right hand side beside the grip.
 Open the cover using the tab until the
tab is at the top right hand side as
shown.
 Insert the flacon in the opening as far
as it will go.
Markers  and  must line up with
one another.
 Turn the outer ring  clockwise a
little.
Marker  must be in position : this
is the position at which you can feel
a resistance.

Miele TSB 143 WP Specifications

General

Drum type	Honeycomb
Door color	White
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Drum volume	120 L
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Delay start (max)	24 h
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Number of drying programs	11
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
