Miele TSB 143 WP User Manual

Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
64
5. Change over the door hinge on the
door
The door hinge is secured to the door
with 2 angled rods. These rods need
to be removed with a screwdriver or
pointed pliers.
 Insert the end of the screwdriver
blade under rod  and rotate it so it
is in an upright position. Do the same
to the other rod.
 Use the screwdriver or pointed pliers
to guide first one then the other rod
 to the middle until each can be re-
moved.
Tip: In some circumstances, the rods
can be difficult to dislodge. Moving the
screwdriver with a levering action while
pulling at the same time may help to
work the rods free.
 Remove the door hinge and turn it
through 180°.
 Fit the door hinge on the opposite
side of the door.
 Secure the door hinge with the two
rods .
 Position the tip of the screwdriver un-
der the end of the rod and then push
it into its resting position .

Miele TSB 143 WP Specifications

General

Drum type	Honeycomb
Door color	White
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Drum volume	120 L
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Delay start (max)	24 h
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Number of drying programs	11
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
