Installation
31
Before installation
 Befor
e installing the appliance,
read all of the information contained
in this chapter and also in the
"IMPORTANT SAFETY
INSTRUCTIONS" section.
Installation parts
4 screws, 6 9/16" x 4 5/16"
(7 x 110 mm) and
4 plugs, 3/8" x 3 1/8" (10 x 80 mm)
for securing the ventilation hood to the
ceiling (not for use in USA / CDN).
The screws and plugs are designed
for use in
solid ceilings only.
Use different fasteners for other
cei
ling construction types. Make
sure that the ceiling can support the
load.
4 extension piece holders
for aligning and securing the telescopic
chimney
4 screws M3/16" x 5/16"
(M4 x 8.5 mm)
for securing the extension piece
holders.
14 screws M3/16" x 5/16"
(M4 x 8 mm)
for securing the spacer frame and
sec
uring the hood to the installation
frame.
1 screw M3/16" x 5/8" (M4 x 16 mm)
for securing the chimney.
DUI 32 recirculation kit for
r
ecirculation mode
(not supplied, available as an optional
accesso
ry). The kit includes a
directional unit, aluminum hose, and
hose clips.
