Maintenance
Only use a genuine Miele hose that has
been pressure tested to withstand at
least 7,000kPa should you ever need a
replacement.
 Damage caused by dirty water.
A filter is located in the open end of
the inlet hose and another in the in-
take point to protect the inlet valve in
the washing machine.
These filters must not be removed.
Hose extension
Longer hoses 2.5 or 4.0m in length are
available from your Miele Dealer or
Miele as optional extras.
Water drainage
The suds are drained through a drain
pump with a 1m high delivery head. For
the water to drain freely, the hose must
be free of kinks.
If required, the hose can be extended to
a length of up to 5m. Accessories are
available from your Miele dealer or from
the Miele Customer Service Depart-
ment.
For drain heights of more than 1m (up
to a maximum delivery head of 1.8m), a
replacement drain pump will need to be
fitted. Please contact Miele for advice.
For a drain height of 1.8m, the hose can
be extended to a length of up to 2.5m.
Accessories are available from your
Miele dealer or from the Miele Cus-
tomer Service Department.
Drainage options:
1. Directed into a sink or basin:
Please note:
– Hook the hose over the edge and
secure it.
– If the water is pumped into a
washbasin, make sure that it can
drain away freely. Otherwise there
is a risk of water overflowing or of
some of the drained water being
sucked back into the machine.
2. Connected securely to a plastic drain
pipe with a rubber nipple (there is no
need to use a siphon).
3. Connected securely to a floor drain
(gully).
4. Connected securely to a washbasin
with plastic nipple.
