Technical data
86
Height 850 mm
Width 596 mm
Depth 643 mm
Depth with door open 1077 mm
Height for building under 850 mm
Width for building under 600 mm
Weight Approx. 96 kg
Capacity 8 kg dry laundry
Voltage See data plate
Connected load See data plate
Fuse rating See data plate
Consumption data See “Consumption data”
Minimum water flow pressure 100 kPa (1 bar)
Maximum water flow pressure 1000 kPa (10 bar)
Intake hose length 1.60 m
Drain hose length 1.50 m
Mains connection cable length 2 m
Maximum drain pump head height 1 m
Maximum drain hose length 5 m
LEDs Class 1
Test certificates awarded See data plate
Frequency band 2.412 GHz – 2.462 GHz
Maximum transmitting power < 100 mW
