Installation
*INSTALLATION*
91
The water protection system
The Miele water protection system pro-
tects all parts of the washing machine
from water damage.
The system consists of three main com-
ponents:
- the inlet hose
- the electronic unit and drainage and
overflow protection
- the drain hose
The Waterproof System (WPS)






a
Two solenoid valves
b
Double-skinned inlet hose
c
Sump
d
Float switch
e
Electronic unit
f
Drain pump
Inlet hose
- The casing on the inlet hose contains
two solenoid valves , which cut off
the water intake directly at the stop-
cock. These valves provide two-fold
protection. In the event that one of
the valves is faulty, the other valve will
cut off the water intake.
Blocking the water intake at the stop-
cock means that the inlet hose is only
under pressure whilst water is being
taken into the machine. For the re-
mainder of the time, pressure on the
inlet hose is negligible.
- Protection against the solenoid valves
bursting
The solenoid valves are pressure
tested to between 7,000kPa and
10,000kPa against bursting.
- The double-skinned inlet hose  has
a pressure-resistant inner hose and a
protective sleeve. Any leaking water is
fed into the sump  through this pro-
tective sleeve. A float switch 
closes the solenoid valves, preventing
any more water flowing into the ma-
chine and water in the suds container
is pumped away.
