14. Insert the screws of the locking ring and tighten them clockwise.
15. Remove the bleeder screw
on the valve
head by turning it counter-clockwise.
16. Wrap the manometer thread
with Teflon
tape
.
17. Screw in the manometer at the removal
position of the bleeder screw by turning it
clockwise.
The filter vessel is prepared.
Fitting the line connections
Use suitable pool hoses Ø 32 / 38 mm for the described connections. Other pool hoses (such as INTEX
with threaded connection) require additional adapters. For the matching adapters, visit our web shop at:
www.steinbach-group.com
Some hoses, such as the pressure hose
, are very stiff. Place them in the sun before
use so that the heat makes them more flexible.
To connect a swimming pool hose to the pump
or filter vessel, proceed as follows:
1. Guide a hose clamp over the hose.
2. Push the hose onto the hose connection.
3. Fix the hose clamp on the hose connection
using a Phillips screwdriver PH1.
The swimming pool hose is connected.
Only hand-tighten all screw connections. Excessive tightening of the screw connections
damages gaskets and plastic components.
29
