TECHNICAL DATA
Power source:
AUTOMIG
223i/223i DUO
AUTOMIG
223i Boost/223i DUO Boost
AUTOMIG
273i
AUTOMIG
273i Boost
Mains voltage (50Hz-60Hz) 3x400V ±15% 3x230/400V ±15% 3x400 V ±15% 3x230/400 V
±15%
Mains voltage (50Hz-60Hz) 1x230V 1x230V
Fuse 10A 16A 10 A 16A
Mains current, effective 6.0A 7.1A 7.6 A 10.5A
Mains current, max. 10.1A 29.9A 13.2 A 42.0A
Powe
r
, (100%) 4.2kVA 1.6kVA 5.3 kVA 2.4kVA
Powe
r
, max 7.0kVA 6.9kVA 9.1 kVA 9.7kVA
Open circuit powe
r
20W 30W 20 W 30W
Efficienc
y
0.90 0.84 0.88 0.84
Efficiency facto
r
0.87 0.99 0.93 0.99
Current range 10-220A 10-220A 10-270 A
10-270 A
Duty cycle 100% at 20°C 180A 115A (140A)* 230 A
150A (180A)*
Duty cycle 60% at 20°C 220A 150A (175A)* 245 A
180A (200A)*
Duty cycle 100% at 40°C 145A 70A (81A)* 175 A
95A (107A)*
Duty cycle 60% at 40°C 170A 86A (108A)* 195 A
110A (126A)*
Duty cycle max. at 40°C 30% 14% (16%)* 25 %
12% (13%)*
Open circuit voltage 52V 52V 52 V
52 V
1
Sphere of application
S
S
S
S
2
Protection class IP 23 IP 23 IP 23
IP 23
Norm
EN/IEC60974-1
EN/IEC60974-5
EN/IEC60974-10 (Class A)
Dimensions (hxwxl) cm 55x25x64 (223i)
96x57x87 (223i DUO)
55x25x64 (223i Boost)
96x57x87 (223i DUO Boost)
55x25x64 55x25x64
Weight 25 kg (223i)
54 kg (223i DUO)
27 kg (223i Boost)
56 kg (223i DUO Boost)
26 kg 28 kg
* Data for Boost-version are stated at 1x230V mains supply
Data in parenthesis are stated at 3x400V mains supply
1
S
This machine meets the demand made for machines which are to operate in areas with increased hazard of electric chocks
2
Equipment marked IP23 is designed for indoor and outdoor applications

Migatronic AUTOMIG 223i/273i Specifications

General

Brand	Migatronic
Model	AUTOMIG 223i/273i
Category	Welding System
Language	English
