Migatronic AUTOMIG

12
Connection and operation
Assembly of parts in wire feed unit (two-roll wire feed system)
Assembly of parts in wire feed unit (four-roll wire feed system)
The pressure of the thumbscrew is adjusted to allow the wire feed roll just to slide on the wire
when this is stopped at the contact tip.
x2
1
1
2
2
3
3
x4
Please note that capillary tubes
must be ordered separately if
ZA connection is mounted.
