QUICKGUIDE
OMEGA
2
BASIC II
SE
501
13770 I
Process 1,0 mm 1,5 mm 2,0 mm 3,0 mm
Material Tråd Gas S
(m/min)
U0
(V)
S
(m/min)
U0
(V)
S
(m/min)
U0
(V)
S
(m/min)
U0
(V)
Fe 0,8 CO
2
2,5 19,0 4,5 19,5 7,0 21,0 11,0 27,0
Fe 1,0 CO
2
2,0 18,0 2,5 19,0 3,0 20,0 4,5 21,0
Fe 1,2 CO
2
1,0 18,0 2,0 20,0 2,5 21,0 3,5 22,0
Fe 0,8 ArCO
2
3,0 16,0 6,0 18,0 7,5 19,5 11,0 20,0
Fe 1,0 ArCO
2
2,0 15,0 3,0 16,0 4,0 17,0 6,0 19,0
Fe 1,2 ArCO
2
1,5 16,5 2,5 17,5 3,5 18,0 4,5 20,5
Fe 1,6 ArCO
2
1,0 17,0 2,0 18,0 2,5 18,5
CrNi 1,0 ArCO
2
3,0 15,0 4,0 16,0 6,0 17,0 8,5 20,0
CrNi 1,2 ArCO
2
2,0 15,0 3,0 16,0 3,5 16,5 6,0 18,0
AI 1,0 Ar 4,0 14,5 6,0 15,0 7,5 16,0 9,0 19,0
AI 1,2 Ar 3,5 13,0 5,0 15,0 8,0 16,0 9,0 17,0
Process 4,0 mm 6,0 mm 10,0 mm
Material Tråd Gas S
(m/min)
U0
(V)
S
(m/min)
U0
(V)
S
(m/min)
U0
(V)
Fe 0,8 CO
2
13,0 29,0 18,0 30,0 24,0 37,0
Fe 1,0 CO
2
6,0 22,5 9,0 24,5 14,0 32,0
Fe 1,2 CO
2
4,5 23,0 7,5 28,5 11,0 36,0
Fe 0,8 ArCO
2
14,0 26,0 18,0 31,0 24,0 33,0
Fe 1,0 ArCO
2
8,0 20,0 11,5 26,5 16,0 30,0
Fe 1,2 ArCO
2
5,5 20,5 8,0 29,0 10,0 32,0
Fe 1,6 ArCO
2
3,0 19,5 4,0 22,0 5,5 29,0
FeFlux 1,2 ArCO
2
6,0 21,0 8,0 25,0 11,0 28,0
CrNi 1,0 ArCO
2
9,0 25,0 10,0 27,0
CrNi 1,2 ArCO
2
8,0 24,0 10,0 24,0 12,0 31,0
AI 1,0 Ar 11,0 22,0 13,0 25,0 15,0 27,0
AI 1,2 Ar 10,0 18,0 13,0 23,0 15,0 26,0
Svetstabell (inställda värden) BASIC II - Fabriksinställning
Inställningsmöjligheter Område Steg Fabriksinställning Enhet
2T/4T
Primära parametrar:
1 Trådhastighet OMEGA
2
300 1,5 - 18,0 0,1 3,0 m/min
Trådhastighet OMEGA
2
400/550 1,5 - 27,0 0,1 3,0 m/min
2 Ljusbågespänning OMEGA
2
300 13 - 32 0,1 18,0 V
Ljusbågespänning OMEGA
2
400/550 13 - 37 0,1 18,0 V
Sekundära parametrar:
1 Induktans -5,0 - +5,0 0,1 0,0 -
2 Gasförströmning 0,0 - 10,0 0,1 0,2 s
3 Krypstart Off / 1,5 - Max. 0,1 2,0 m/min
6 Burnback 1 - 30 1 5 ms
7 Gasefterströmning 0,0 - 10,0 0,1 3,0 s
t Punkttid 0,0 - 50,0 0,1 0,0 s
G Gas Manuell 0,5 - 27,0 l
r Fjärrkontroll 0 = intern
1 = brännarkontroll
2 = fjärrkontroll
C Kylning ON / Off
L Låsfunktion ON / OFF
To Next Page
