MIJO MT02 - MT01 Initial Wheelchair Connection; Securing the Handbike to Wheelchair; Wheelchair Frame Clamping Procedure

7
MT01 First time connecting with wheelchair instruction
1. Press the safety catch lever to keep the body standing steadily.
2. As shown in figure,Clamp the pipe clamp to a suitable frame of the wheelchair
(Note: After the pipe clamps on both sides clamped, the bubble of gradienter should
be in the middle);
The knob must be tightened
40 CM
