4. Bind procedure, programming
VBar will go into bind mode after approx. 10 seconds. The LED
will ash green-red to indicate it‘s ready for binding.
Refer to your VBar Control Manual to bind your VBar to your
VBar Control Transmitter.
5. Wiring your VBar
Connectors
ESC Electronic Speed Controller
TAIL Tail servo
CH1-4 Swash plate servos according to diagram in the software
AUX1-3 Additional functions
RPM RPM sensor input
USB USB wire
TELE 1, TELE 2 Telemetry bus for VBar Control.
Power supply may be connected to any port. There is no voltage divider
needed for rpm sensors. Make sure all components support the input voltage
connected. For further applications (additional functions) see App in VBar
Control and online manual on www.vstabi.info.
6. Pre-ightcheck
Before each ight you must double-check the active
direction of the swash plate and the tail rotor. To do so, lift
the helicopter up and move it along the three axis.
