MikroTik CRS354-48P-4S+2Q+RM User Manual

6.
Please ensure the placement of the device in a dry and ventilated environment. Ingress rating IP20.
We recommend Cat6 cables for our devices.
The mounting and configuration of this device should be done by a qualified person.
Extension slots and ports
48 Gigabit Ethernet ports supporting 802.3af/at PoE.
Four 10G SFP+ ports.
Two 40G QSFP+ ports.
1x RJ45 console port (set at 115200bits/s, 8 data bits, 1 stop bit no parity).
1x 10/100Mbit Ethernet port for management access.
Four cooling fans with automatic speed control.
Please visit wiki pages for MikroTik SFP module compatibility and configuration table: https://wiki.mikrotik.com/wiki
/MikroTik_SFP_module_compatibility_table
Powering
The device accepts power from the input of 100 – 240 V AC .
Nominal voltage 53 V.
Nominal amperage 13.5 A.
The power consumption of this device under maximum load is up to 85 W. With attachments 800 W.
Power output
The device supports PoE 802.3af/at out from Ethernet 1 - 48 port, you can power Mikrotik devices which supports powering through Ethernet.
Output per port (53V out) 570 mA
Output per port (26V out) 1000 mA
Total output power 700 W
Total output 27 A at 26 V, or 13,2 A at 53 V.
Configuration
RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to
the possibilities: . In case the IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC https://mt.lv/help https://mt.lv/winbox
address of the device from the LAN side. When using Winbox on login the default configuration settings will be shown.
CRS Router configuration manual https://wiki.mikrotik.com/wiki/Manual:CRS_Router
For recovery purposes, it is possible to boot the device for reinstallation, see a section .Reset button

MikroTik CRS354-48P-4S+2Q+RM Specifications

General

Switch type	Managed
Switch layer	L3
Form factor	1U
Certification	CE/RED, EAC, RoHS
Rack mounting	Yes
Console port	RJ-45
SFP+ module slots quantity	4
QSFP+ module slots quantity	2
Installed SFP modules quantity	-
Fast Ethernet (copper) ports quantity	1
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
Power over Ethernet (PoE) voltage	53 V
Power over Ethernet (PoE) power per port	30 W
Operating temperature (T-T)	-20 - 60 °C
Memory type	Flash
Flash memory	16 MB
Internal memory	64 MB
Processor model	Qualcomm Atheros QCA9531
AC input voltage	100 - 240 V
Power consumption (max)	800 W
Power consumption (typical)	85 W
Networking standards	IEEE 802.3af, IEEE 802.3at
Cables included	AC
MAC address table	- entries

Weight and Dimensions

Depth	382 mm
Width	443 mm
Height	44 mm
