MikroTik hAP ac3 User Manual

1.
2.
3.
4.
5.
6.
1.
2.
3.
Scan QR code and choose your preferred OS.
Install and open application.
By default, the IP address and user name will be already entered.
Click Connect to establish a connection to your device through a wireless network.
Choose Quick setup and application will guide you through all basic configuration settings in a couple of easy steps.
An advanced menu is available to fully configure all necessary settings.
Powering
The device accepts powering from the adapter and PoE:
Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-28 V DC.
PoE in 18-28 V DC.
The power consumption under maximum load can reach 12 W, with attachments 30 W.
Base plate mounting instruction
The base plate comes with the package, in order to assemble please follow these instructions.
Place the small tip of the base plate into the case on the bottom of the device and fold it down.
While holding with both hands, use fingers to slightly press it and push down till it locks, follow the sequence on the illustration.
Configuration

MikroTik hAP ac3 Specifications

General

CPU	IPQ-4019
CPU core count	4
CPU nominal frequency	716 MHz
RAM	256 MB
Storage	128 MB
Storage type	NAND
Wireless 2.4 GHz Max data rate	300 Mbps
Wireless 5 GHz Max data rate	867 Mbps
Wireless Standards	802.11a/b/g/n/ac
PoE in	802.3af/at
Operating System	RouterOS
License level	4
Operating temperature	-40°C to 70°C
Ethernet Ports	5
Antenna gain dBi for 2.4 GHz	2.5 dBi
Antenna gain dBi for 5 GHz	5.5 dBi
USB Port	1
Power Input	12-28 V
PoE out	Passive PoE
