The Software Reset 2 button (TP12) reset hole, which resets both boot loader settings and RouterOS setting by
default, can be disabled in this menu (it will still reset the boot loader settings).
Software Reset
It is possible to reset all software configuration by using the Software Reset 2 button hole (C229, see
schematic) during the power-up. No confirmation or passwords will be asked, so use with caution. This feature
can be disabled in the “system routerboard settings” menu by switching the “enable-jumper-reset”
parameter to “no”. Simply use a metal object to short circuit the metallic reset hole (TP12) while booting.
Appendix
Connector Index
J404
MicroSD slot (bootable)
J401
RS232C male DB9 serial port
2
RxD (Receive Data)
3
TxD (Transmit Data)
5
GND
7
RTS (Request to Send)
8
CTS (Clear to Send)
J402
Alternate serial port (see 11 for pinout)
J701-J705
(Group one)
J901-J905
(Group two)
RJ45 Gigabit Ethernet 1000Base-T ports in two switch groups
J501
Bypass port group
J5
RJ45 Gigabit Ethernet 1000Base-T port with PoE (Ether13)
J10
Power jack (12 V DC, positive contact is the central pin)
J11
Alternative power Jack (12 V DC, positive contact is the leftmost pin, closer to J10)
JP1201
JP1202
JP1203
JP1204
DC Fan 1 connector
1
GND
2
+5.5 V DC
3
Rotation speed feedback

MikroTik RouterBOARD 1100 Specifications

General

Brand	MikroTik
Model	RouterBOARD 1100
Category	Network Router
Language	English
