MikroTik RouterBOARD 1100 - Specifications; Hardware Guide; Memory and Storage Devices

4
Specifications
RouterBOARD 1100/AH
CPU
RB1100: MPC8544 800MHz
RB1100AH: P2010 1066MHz
RB1100AHx2: P2020 1066MHz dual core CPU with IPsec acceleration
Memory
SODIMM slot, no onboard module
Boot loader
RouterBOOT
Data storage
onboard NAND memory chip
Ethernet
Thirteen 10/100/1000 Mbit/s Ethernet ports supporting Auto-MDI/X
MiniPCI slot
-
Expansion
-
CompactFlash slots
One microSD card slot on board, accessible by opening the case
Serial port
One DB9 RS232C asynchronous serial port
LEDs
Power and User LED
Beeper
+
Power at the board
Power jack: 12-24VDC; PoE on Ether13: 12-24VDC
Power at the case
IEC C14 jack: 110-220VDC
Fans
JP1202 and JP1204 - 12V; 0,2A max.
JP1201 and JP1203 - 3,3V; 0,3A max.
Only one Fan in each pair will rotate, other will start when first fails.
Only one pair can be connected at the same time (two fans).
Dimensions
Board: 135 mm x 291 mm
1U rackmount case: 44 x 176 x 442 mm
Weight
365g board only, 1275g assembled with case
Temperature
Operational: -20°C to +65°C (-4°F to 149°F)
Humidity
Operational: up to 70% relative humidity (non-condensing)
Power consumption
12W min/25W max
Hardware Guide
Memory and Storage Devices
Memory
There is no onboard memory, but the device has a SODIMM slot for one DDR2 module, it is recommended to
use modules with at least 667MHz (PC-4200). The RB1100 device supports modules of up to 2GB, but due to
software limitations, RouterOS will be able to use only 1.5GB of it.
microSD slot
The board has one microSD card slot which supports microSD and microSDHC cards for expanding the storage
in RouterOS
