MILL Invisible Series - Minimum distances; Description of heater; Assembly; Temperature calibration

5
EN
It is also normal for the heater to make “sounds” when it warms up or cools down.
Minimum distances
100 mm
50 mm50 mm
100 mm
100 mm in front
of heater
Description of heater
 
MILL INVISIBLE
1. On/Off
2. Wall bracket
3. Temperature sensor
Heat emission
5. Thermostat
Steel front
MILL GLASS
1. On/Off
2. Wall bracket
3. Temperature sensor
Heat emission
5. Thermostat
Glass front
Assembly
 
A. Drill holes in the wall for holes 1 & 2. Then drill holes in the wall for the topmost holes


C. Place the heater on the lower lugs on the bracket, then hang the heater on the
upper lugs (lift the heater slightly to align the heater with for the upper lugs). Screw in
the locking screws on the top of the bracket (clockwise)
Attention! Horizontal placement only
Temperature calibration
 
It may occur deviation between the temperature registered by the heater and the actual
temperature in the room. This can be caused by several reasons, however, the most com-
mon is that the heater is placed in a fair distance from where you usually reside. When you
set the temperature to for example 22 degrees, it is only natural that you expect the same
temperature where your sofa is placed for instance. However, the temperature sensor is
placed on the product itself, and therefore a deviation in temperature may occur. To adjust
this, all Mill heaters are equipped with a calibration function, which enables you to adjust
