II. INSTALLATION
Before installation, it is recommended that the support structure meets or exceeds requirements specified
General Requirements, Part B Limitations.
y
system. Also, check for missing or damaged parts. Refer to inspection
ection for further details.
WARNING: Do not use if any damaged or missing parts are detected.
A. PART IDENTIFICATION:
in
Before installation of this equipment, User must read and understand all instructions and carefull
inspect all equipment to ensure that it is in usable condition. User should familiarize his/herself
with all components of this
s
Anchor
Points
Horizontal Boom
Hitch Pin
Push Pin
Vertical Boom
Steering handles
Lifting Rings
Brake Jack
Swiveling Casters
Brake Jack
Brake Jack
Push Pin
Main Body
Swiveling Casters
Handle
Pushing
Hitch Pin
9081MRMB
Front of Unit
Counter Weights
9081WT/300LB
*
*
Stabilizer
Fig. 1
Optional Equipment *
