START UP
For successful start up, insure that all related system components such as belt
scale and speed sensor are properly installed and connected.
ORIENTATION
Display and Keypad
The BW100 operates under two modes: ‘run’ and ‘program’. When the unit is initially
powered, it starts in the program mode.
If the program mode is idle, it reverts to the run mode after 10 minutes.
98\03\09
LCD
Keypad
balance switch ,SW2
balance potentiometer, P1
START UP
PL-531 21
