P014 design speed
Specifies the design speed for the conveyor belt.
Speed units are: metre/s if P005 = 1 or 2
feet/min if P005 = 3, 4 or 5
P015 speed constant
This value multiplied with the speed sensor frequency, calculates the
actual belt speed.
entry: If speed input is wired for constant speed
(TB1 5/6 jumpered), value defaults to ’100’.
enter the speed constant = from the supplied design data sheet
or
=
speed sensor pulses per revolution*
pulley circumference (m or ft)/ revolution
* refer to speed sensor nameplate or consult Mass Dynamics or their agent
P016 belt length
The length of the conveyor belt (one belt revolution).
Length units are: metre if P005 = 1 or 2
ft if P005 = 3, 4 or 5
enter the belt length
P017 test load
The load to be referenced when performing a span.
Load units are: kg/m if P005 = 1 or 2
lb/ft if P005 = 3, 4 or 5
End of ’short program’ parameters. A calibration can now be performed.
PARAMETER DESC.
PL-531 58
