Milltronics VM16 User Manual

Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
MC5 Spindle Drive Parameters - Single speed 15/10 HP
2-27-01
MC5 2011
Parameter Name 15/10 HP Unit
6422
Electronic
Orient
7.5 KVA
INITIALIZE
CONSTANTS
A1-01 Access Level 4
A1-02 User Setting 3
PROGRAM
CONSTANTS
B1-01 Reference Selection 1
B1-07 LOC/REM RUN Sel 1
B1-02 Operation Method 1
AUTO TUNING
CONSTANTS
C1-01* Accel Time 1 1.5 sec
C1-02* Decel Time 1 2. sec
C1-03* Accel Time 2 .2 sec
C1-04* Decel Time 2 .2 sec
C1-07* Accel Time 4 10. sec
C1-08* Decel Time 4 10. sec
C1-11 Acc/Dec SW Freq 0. Hz
C2-01 SCrv Acc @ Start .20
C2-02 SCrv Acc @ End .45
C2-03 SCrv Dec @ Start .20
C2-04 SCrv Dec @ End 0
C5-01* ASR P Gain 70.
C5-02* ASR I Gain .1
C5-03* ASR P Gain 2 80.
C5-04* ASR I Time 2 .3 sec
C5-06 ASR Delay Time 0.
C6-01 Carrier Freq Max 15. KHz
C8-02 Special
C8-03 Special
C8-04 Special %
C8-06 Special Ms
C8-07 Special %
C8-27 Inverse rate current A
C8-28 DCCT Gain
D1-09 Jog Reference 6. Hz
MOTOR
CONSTANTS
E1-02 Motor Selection 0
E1-04* Max Frequency 200. Hz
E1-05 Max Voltage 142. V
E1-06 Base Frequency 50. Hz
E1-13 Base Voltage 142.1 V
E2-01 Motor Rated FLA 50. A
E2-02 Motor Rated Slip 1.46 Hz
E2-03 No-load Current 29.2 A
E2-04 Number of Poles 4
26 Rev.9
