Milltronics VM16 User Manual

Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
MC5 2011 MC5 2011 MC5 2011
Parameter Name 20/15HP 20/15HP 20/15HP Unit
6422 5422 6422
WINDING
CHANGE
CONSTANTS
P1-02 Frequency Width 6.0 6.0 6.0 Hz
P1-03 Ansback Det Time 0.50 N/A N/A Sec
P1-04 Wye Winding Sel 1 1 1
P1-05 CASE Param 5 .01 .01 .01
ELECTRONIC
ORIENT
CONSTANTS
P3-01** Orient Position 0 to 4095 N/A N/A
P3-02 Position Gain H 20 N/A N/A
P3-05 Ore Set Pulse 10 N/A N/A
P3-06 Ore Reset Pulse 10 N/A N/A
P3-07* Orient Speed 150 N/A N/A
P3-08 Gear Ratio 1 N/A N/A
P3-11 Gear Direction 0 N/A N/A
P3-12 Dither Level 0 N/A N/A
* Parameters will vary depending on RPM option of machine (See Chart Below)
** Orient Position will vary on every machine.
This listing contains the spindle drive parameters that have been changed by Milltronics Manufacturing.
All other parameters remain unchanged and are the factory default settings from Yaskawa.
Constant Name 6K RPM 8K RPM 12K RPM
C1-01* Accel Time 1 2. 3. 2.
C1-02* Decel Time 1 3. 12. 7.
C1-03* Accel Time 2 .4 .4 .4
C1-04* Decel Time 2 .4 .4 .4
C5-01* ASR P Gain 20. 20. 20.
C5-02* ASR I Gain .5 .5 .5
C5-03* ASR P Gain 2 100 100 100
C5-04* ASR I Time 2 .3 .3 .3
E1-04* Max Frequency 200. 266.7 200.
P3-07* Orient Speed 150 400 150
Please consult Milltronics Service Department for current parameters.
31 Rev.9
