Milltronics VM30 User Manual

Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
MC5 Spindle Drive Parameters 30/22 HP
4-10-01
MC5 2015 MC5 2015 MC5 2015
Parameter Name 30/22 HP 30/22 HP 30/22 HP Unit
6422 5422 6422
Electronic
Orient
Mechanical
Orient
Mechanical
Orient
24 KVA 24 KVA 24 KVA
INITIALIZE
CONSTANTS
A1-01 Access Level 4 4 4
A1-02 User Setting 3 3 3
PROGRAM
CONSTANTS
B1-01 Reference Selection 1 1 1
B1-07 LOC/REM RUN Sel 1 1 1
B1-02 Operation Method 5 4 4
B2-03 D/C Injection Braking .25 .25 .25
AUTO TUNING
CONSTANTS
C1-01* Accel Time 1 2.0 2.0 2.0 sec
C1-02* Decel Time 1 5.0 5.0 5.0 sec
C1-03* Accel Time 2 0.4 0.4 0.4 sec
C1-04* Decel Time 2 0.4 0.4 0.4 sec
C1-07* Accel Time 4 1.0 1.0 1.0 sec
C1-08* Decel Time 4 2.0 2.0 2.0 sec
C1-11 Acc/Dec SW Freq 133.0 133.0 133.0 Hz
C2-01 SCrv Acc @ Start .20 .20 .20
C2-02 SCrv Acc @ End .20 .20 .20
C2-03 SCrv Dec @ Start .4 .4 .4
C2-04 SCrv Dec @ End .3 .3 .3
C5-01* ASR P Gain 20 20 20
C5-02* ASR I Gain .5 .5 .5
C5-03* ASR P Gain 2 30.00 30.00 30.00
C5-04* ASR I Time 2 0.300 0.300 0.300 sec
C5-06 ASR Delay Time 0 0 0
C6-01 Carrier Freq Max 4.0 4.0 4.0 KHz
C8-02 Special 0.10 0.10 0.10
C8-03 Special 0.0 0.0 0.0
C8-04 Special 5 5 5 %
C8-06 Special 0.0 0.0 0.0 Ms
C8-07 Special 5 5 5 %
C8-27 Inverse rate current 49.0 49.0 49.0 A
C8-28 DCCT Gain 1.154 1.154 1.154
D1-09 Jog Reference 1.00 1.00 1.00 Hz
MOTOR
CONSTANTS
E1-02 Motor Selection 1 1 1
E1-04* Max Frequency 200. 200. 200. Hz
E1-05 Max Voltage 122.4 122.4 122.4 V
E1-06 Base Frequency 40.0 40.0 40.0 Hz
E1-13 Base Voltage 118.7 118.7 118.7 V
E2-01 Motor Rated FLA 67.4 67.4 67.4 A
E2-02 Motor Rated Slip 0.62 0.62 0.62 Hz
E2-03 No-load Current 32.4 32.4 32.4 A
32 Rev.9
