Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
Centurion 6 CNC Connector Signal Listing
Pin 5 - Serial I/O TXD Pin 10 - DC ground
Keyboard DIN Connector (J1)
Pin 1 - Keyboard EXCLK Pin 4 - DC ground
Pin 2 - Keyboard EXDAT Pin 5 - +5 VDC
Pin 3 - No connect
Connectors in the Mag Box
Connectors ATC1 and 1-1E
Pin 1 - Tool changer carousel power – return Pin 9 - Tool changer arm out prox
Pin 2 - Tool changer carousel power –
clockwise
Pin 10 - Tool arm in/tool arm out prox
Pin 3 - Tool changer carousel power - counter
clockwise
DC ground
Pin 4 - Home/at pocket prox DC ground Pin 11 - Key
Pin 5 - Home/at pocket prox +24 VDC Pin 12 - Tool changer arm in/out signal
Pin 6 - Tool carousel home prox Pin 13 - 20 pocket tool changer door
Pin 7 - Tool carousel at pocket prox open signal
Pin 8 - Tool changer arm in prox Pin 14 - Tool changer arm & door solenoids common
Connector ATC2
Pin 1 - Spindle orient solenoid signal Pin 8 - Spindle orient prox chassis ground
Pin 2 - Power drawbar solenoid signal Pin 9 - Drawbar solenoid chassis ground
Pin 3 - Spray mist air solenoid signal Pin 10 - Key
Pin 4 - Spindle orient solenoid +24 VDC Pin 11 - Spray mist solenoid chassis ground
Pin 5 - Power drawbar solenoid +24 VDC Pin 12 - Spindle orient prox signal
Pin 6 - Tool Out switch Pin 13 - Spindle orient prox +24 VDC
Pin 7 - Spray mist air solenoid +24 VDC Pin 14 - Spindle orient prox DC ground
Connector on +24 VDC Regulated Power Supply
Pin 1 - 110 VAC line Pin 8 - No connect
Pin 2 - 110 VAC return Pin 9 - No connect
Pin 3 - No connect Pin 10 - No connect
Pin 4 - +24 VDC Pin 11 - DC ground
Pin 5 - +24 VDC Pin 12 - DC ground
Pin 6 - Key Pin 13 - DC ground
Pin 7 - No connect Pin 14 - DC ground
Connector COM1 (on Mag Panel)
Pin 2 - RXD
Pin 3 - TXD
Pin 7 - Ground
All other pins no connect
45 Rev.9
