6
Pellerin Milnor Corporation
BNCLJO10 / 2020403
BNCLJO10 0000212821 B.8 9/29/20 9:37 AM Released
2.3 How to Use the MilTouch™ Controller
BNCLJO10.C01 0000212820 A.10 B.8 C.3 9/11/20 8:32 AM Released
The Milnor
®
MilTouch™ washer-extractor controller uses a touch-sensitive display screen to op-
erate the machine. All the functions and information you need to process goods appear on this
screen.
CAUTION: Excessive pressure — can damage the display screen.
� Do not push hard on the glass.
� Use only a finger to touch the glass. Do not touch the screen with a
tool.
Turn the master switch on (
) to apply power to the control system. The Home display appears
on the touchscreen.
2.3.1 The Home Display
BNCLJO09.C01 0000211248 A.10 B.8 B.16 9/24/20 11:49 AM Released
The display pictured in the following figure, subsequently referred to as the Home display, is
used to access all the other displays. Buttons labelled with an asterisk (*) are not used during rou-
tine operation. For additional information on those buttons and the displays they access, see the
separate controller reference manual.
From the Home display, and with a load of goods in the machine, you can select and run wash
formulas.
If your machine is part of a Mildata
®
network, you can also run formulas programmed into the
Mildata
®
computer remotely from the Home display.
Controls
9
